2012 Gentex Mirror Wiring Diagram Toyota Tundra Forum

Pin 1- Pink 12 volts Pin 2- Black ground Pin 3- Lt.

Gentex 12 pin wiring diagram. Here is the low down on the connections to a Gentex mirror with comp and temp cut from a late model GM product. Disconnect vehicles negative battery terminal. A Using a multi-meter find a wire exiting the fuse block that tests 12V with vehicle ignition in the ACC ON and OFF positions.

Great Upgrade for many Convertibles. This Mirror was removed from a 2004 Subaru Outback. And its a 12 pin connector obv not all being used edit.

The connector pin numbers are found on the wire incursion side of the mating connector. Heres how Im going to wire my car. And the third wire is for ground.

11- keypad signal out for On-star pressing any button puts out a 5v multiplexed signal on this pin - so you cant just use the buttons to control whatever you want to. Hope this helps someone. Green Backup Lights Pin 4- NOT USED Pin 5- NOT USED Pin 6- Dark GreenWhite -Temp Probe Pin 7- Yellow - Temp Probe Spliced into wiring under airbox using DR GRNWT and YELLOW for temp probe.

That leaves Pins 3 and 4 - green and white wires on the mirror side - for constant and switched power. PIN 12 AND PIN 15 1773241 Solid joists shall be considered equivalent to beams for smoke detector spacing guidelines. The Donnelly mirrors use the same 7-pin plug as the Gentex but the pin-outs are different.

Pin 1 - 12 volts Pin 2 - Courtesy lamp input Pin 3 - varies depending on mirror features Pin 4 - varies depending on mirror features Pin 5 - Reverse disable 12 volts in reverse Pin 6 - Ground. 6163927195 Toll-free. Gentex Auto-dimming Mirror Wiring Diagram How to install a self dimming and auto dimming mirror from Gentex on a mk5 or mk6 a highline control module and you have to add the wiring to make it work.

Gentex 10 pin GNTX HomelinkCompass or Compass Mirror Wiring Kit. 13 - ignition voltage 12v -main power IN to the mirror 14 - keypad green LED signal. Pin 7 - constant 12 volts When swapping for a Gentex mirror with outside temp Pin 6 - sensor wire doesnt matter which wire Pin 7 - sensor wire doesnt matter which wire ALL Gentex mirrors use the same temp sensor and if the mirror has a compass that is a self contained unit not needing any wires other than what is already hooked up.

GM wire harness color function. PIN 6 Lite Green Black stripe AMBIENT TEMP SENSOR 12V PIN 7 Gray Black stripe AMBIENT TEMP SENSOR GRD PIN 8 Black GROUND BOTTOM ROW PIN 9 Lite Green REVERSE DIM INHIBIT PIN 10 11 12 Empty PIN 13 Yellow 12V SWITCHED POWER PIN 14 15 16 Empty. PIN 3 AND PIN 6 NEUTRAL WHITE WIRE.

15 - keypad red LED signal. A few notes on the mirrors too. Another is for switched 12V which would power the self-dimming feature when the vehicle is on.

Does anyone have the wiring colors to wire this up. Includes 7-wire wiring harness. This is for a Gentex 177dont know about others.

Feb 06 NONE of the wiring diagrams out there match what I have on my 16 pin connector. 62 Route the mirror ground wire black to the ground point. The black mirror wire connects to the gray wblack strip Volt wire ground.

12V Auto Waterproof Fuse Relay Box Block 6 Bosch Style Relay Holder 6 ATCATO Fuse Holder Universal Relay Block Box for 12V Automotive Vehicles Cars Marine Boat Light Equipment 1995 Switch Pros SP-9100 8-Switch Panel Power System With Concealed Mounting Hardware. PIN 4 GRAY TO AUTO DIM OUTSIDE MIRROR PIN 5 PINK TO AUTO DIM OUTSIDE MIRROR PIN 6 DARK GREENWHITE TEMP SENSOR. Diagram BMW Mirror Wiring Diagram Gentex 10 -Pin Wiring-Diagram Gentex Gentex Mirror Connector Diagram Gentex Mirror.

Sorry 12 - keypad supply 5v voltage in for the buttons. PIN 3 AND PIN 6 NEGATIVE BLACK WIRE. Locate constant power 12V constant wire.

Gentex GNTX-221 Rearview Mirror with Compass Auto Dimming LED Map Lights. There are 5 wires coming out of the mirror. The PN is 92021AJ10A Its a Gentex GHSHL4 Here are the wires I have.

70 12-VOLT POSITIVE WIRE CONNECTION. 1773242 For level ceilings the following shall apply. My guess is that Pin 1 - black wire on both sides - is Ground.

Same Mirror as found in the Jeep Wrangler TJ Lincoln Continental Subaru Forester Subaru Legacy. 1 I want the HomeLink and Auto-dimming to only work when the ignition is On so Im going to cross the yellow and red mirror wiring harness wires with the red Volt wire 12 switched. Does anyone have pin out wire diagram for a gentex mirror model well from what I could find and piece together is pin 6 and 10 are.

PIN 12 AND PIN 15 24 DC VOLTAGE 8240 8243 SERIES. 63 Remove the bolt or screw from the ground point and install the ring terminal over the ground boltscrew. PIN 1 PINK POWER 12 volts.

Gentex Mirror Wiring Diagram - I bought a autodimming mirror that came from a Windstar. 11 b Ensure power in this wire is still present when vehicle key is OFF and label wire CONSTANT 3. Its off a 2011-2012 and has a 12 pin harness.

They can have 10 or 12 pin connectors. PIN 1 2 3 4 5 empty. AND the internal jumper that Subaru relies on in their oem harnessGentex.

Or the wiring diagram that shows what pins go where. Uses Standard Gentex 7-pin Connector. 64 Reinstall and tighten the fastener.

It fits many other Cars. PIN 1 PINK POWER 12 volts PIN 2 BLACK CHASSIS GROUND PIN 3 LIGHT GREEN BACKUP LIGHTS If not using the backup feature connect this to ground otherwise auto dim will not function properly. Here is the pin-out for the Donnelly mirrors.
